7 parts
2 materials
Piece list
001 — 70mm
6 parts| Qty | Dimensions | Names |
|---|---|---|
| 4 | 500 × 95 mm | Planche 2, Planche 3, Planche 4, Planche 5 |
| 2 | 490 × 70 mm | Planche 6, Planche 7 |
003 — 30mm
1 parts| Qty | Dimensions | Names |
|---|---|---|
| 1 | 1200 × 800 mm | Planche 8 |
Cutting plan
mm
Panel width
Panel height
Bar length
Cutting summary
| Material | parts | Qty | Format | Waste |
|---|---|---|---|---|
